Adaptive Vibration Isolators for Avionics and Shipboard Electronics
Shock and Vibration Interface Hardware for Sensitive Defense Electronics
Perseus vibration isolators protect sensitive electronics from platform shock, random vibration, and resonance amplification. Available approaches include adaptive metal dampers, friction damping, high-damping silicone mounts, and integrated module isolation assemblies, with load cases reviewed from 0.05 kg up to 200 kg per unit by configuration.
Core Technical Features
Adaptive Damping Architectures:
Adaptive metal and friction damping concepts help manage resonance zones while preserving isolation behavior outside resonance.
High-Damping Silicone Mounts:
Elastomeric isolators support compact chassis and lightweight payloads where broadband attenuation and weathering resistance matter.
Integrated Module Isolation:
Structural isolation assemblies can combine chassis mounting and vibration protection where SWaP efficiency is important.
Environmental Durability Review:
Salt fog, humidity, ozone, and thermal cycling requirements should be confirmed by platform exposure and test plan.
Typical Applications
-
![]()
Protects mission computers, sensor modules, and avionics racks from vibration-driven connector and PCB fatigue.
Airborne Avionics and Sensor Payloads
-
![]()
Supports equipment isolation where continuous low-frequency vibration and salt-laden environments affect hardware life.
Shipboard Radar and Communication Electronics
-
![]()
Reduces shock and vibration transmission into vehicle-mounted electronics and tactical shelter systems.
Ground Mobile Electronics
-
![]()
Integrated isolation concepts support space-constrained airborne, missile, and mobile payload electronics.
Compact Payload and Guidance Modules
Series Selection Guide
Vibration Isolator Selection Guide
| Parameter | Available Configuration | Engineering Notes |
|---|---|---|
| Isolator Types | Adaptive metal dampers / friction damping / silicone mounts | Select by platform vibration profile and payload sensitivity. |
| Load Capacity | 0.05 kg to 200 kg per unit by configuration | Confirm load per isolator, center of gravity, and safety factor. |
| Operating Temperature | -55°C to +85°C by configuration | Final range depends on material system and exposure profile. |
| Durability Review | Salt fog / humidity / ozone / thermal cycling | Exposure requirements should be mapped to platform environment. |
| Qualification Planning | Defense-grade shock and random vibration profiles | Method, category, curve, and acceptance criteria belong in the program test plan. |
| Integration Data | Mounting envelope / static load / vibration input / target natural frequency | Required before isolator selection or custom review. |
Vibration Isolator Overview
Perseus vibration isolators serve as the interface between sensitive electronics and platform structures. The product family includes adaptive metal dampers, friction damping concepts, high-damping silicone mounts, and integrated isolation assemblies for avionics, radar, shipboard, and ground electronics.
Selection should be based on load per isolator, center of gravity, available mounting envelope, vibration input profile, target natural frequency, environmental exposure, and the program acceptance criteria for shock and random vibration.
- Load definition
Provide payload mass, isolator count, center of gravity, and mounting orientation.- Vibration input
Share random vibration, sine, shock, and resonance concerns where available.- Environment
Confirm temperature, salt fog, humidity, ozone, and service-life expectations.
